Car Audio
MK-425DSP
Name: D1
Type
1. DSP + Amplifier
2. 4ch class AB Amplifier out, 6ch Low-level out
Feature
1. Hi-Fi Bluetooth Module inside
2. PNP installation
• Intelligent High Level Input (Error Protection System)
• Start-Stop ready, Auto Turn-On
• Soft-Clipping (power attenuation) in 2 Ohm operation
• Signal-to-noise Ratio ≥95dB
• Frequency Response 15 Hz – 22 kHz (-0.5dB)
• THD ≤0,1% (1 kHz, 4Ω, 90% Power)
• Dual 28bit, 330 MIPS DSP technology controllable via PC software or APP
• Over 50kinds of Plug+Play cables sets which cover around 300 diffierent car models
• Internal Bluetooth® Module(4.2V) for Hi-Fi Audio Streaming
• P2 : 2Ch mini amplifier to drive subwoofer (optional)
4 x 25/38 Watts RMS @ 4/2 Ohms
4 x High Level Inputs, 2 x AUX/RCA Inputs
4 x Loudspeaker Outputs amplified
6 x Pre-Amplifier Outputs/RCA (configurable via DSP)
Dimensions in mm: 165 (L) x 98 (W) x 32 (H)
MK-425DSP 메뉴얼.pdf
(542.1K)
